Detailed description

    The machine is fully enclosed, all parts are made of stainless steel, equipped with a three-stage purification device, and the filtered air reaches 100,000 levels. Simplified and top equipped with cold wall device, the wall temperature is <80 °C, the material stays on the wall and does not coke and deteriorate, which greatly increases the powder collection rate (up to 95%), and does not produce mixed drugs and sticky walls. phenomenon.



Fundamental:

    The high-speed centrifugal spray device of traditional Chinese medicine extract is the application of centrifugal spray drying technology in the drying of specific materials. It also uses high-speed centrifugal atomizer to disperse the material into a mist, which is in full contact with hot air to complete the instant drying and form a powder. Drying device for the finished product.
    The special dryer for traditional Chinese medicine extract is specially used to solve the spray dryer of traditional Chinese medicine extract and vegetable sputum. It solves the following situations in the drying of traditional Chinese medicine extract in the original LPG high-speed spray dryer:
1. Material sticking wall , the powder collection rate is low;
2. The material stays on the wall for a long time, resulting in coking and deterioration of the material
3. It is difficult to clean and does not meet the requirements of GMP;
4. Low output: LPG-150 spray dryer, its output can only be processed 50-60Kg / h liquid material.

    In view of the above situation, our factory designed the problem of traditional Chinese medicine extract dryer according to the material properties and process requirements of traditional Chinese medicine extract. The color of the dried material is good and does not deteriorate, which greatly improves the economic benefits of the factory. Chinese medicine extract and LPG high speed The centrifugal spray dryer has the following characteristics:
1. It adopts three-stage air purification to make the inlet air reach the requirements of 100,000 grades.
2. The cold wall device is used to make the inner wall temperature reach 80 °C, and the material does not stay on the wall. Coking;
3. The entire volume is 3.5 times that of the original LPG standard centrifugal spray.
4. Adopt quick-opening flushing device, suitable for multi-variety production requirements.
5. Dust-removing dust is used to remove dust, so that dust does not go out and meet environmental protection requirements.
6. Air sweeping device is used, the effect is more satisfactory;
7. Nebulizer Adopt frequency control.
8. Adopt PLG control, program control system screen display;
9. Can be equipped with flushing device; 10. Can be equipped with dry air closed transport.

Technical Parameters:

Note: Some parameters are adjusted according to different materials during design. The design is subject to change.
